One of the main advantages of these modules is their ability to save space on a printed circuit board (PCB). By integrating multiple components like connectors, resistors, capacitors, and inductors, these modules allow for a more compact design without compromising functionality.

​Discrete LAN magnetics, also known as discrete Ethernet transformers, are electronic components that play a crucial role in Ethernet networking.

CAT8 is a twisted-pair copper cable standard that supports 25G Ethernet transmission over distances up to 30 meters. Some of the key characteristics of CAT8 for 25G application include: 1、Bandwidth: CAT8 cables are designed to support a bandwidth of up to 2 GHz, which enables them to transmit data at speeds of up to 25 Gbps.

One of the basic requirements for a LAN magnetic interface circuit is to provide electrical isolation. This is achieved by the use of an isolation transformer. The isolation transformer electromagnetically couples signals (data) from the primary-side (PHY side) to the secondary-side (Cable side).

In the context of home network products, both hubs and switches are devices used to connect multiple devices together within a network. However, there are significant differences between the two in terms of their functionality and how they handle network traffic.

Planar transformer is not only in the application of new energy vehicles, but also can be used in communication power supply, server power supply, module power supply, POE power supply, 5G, ultra-thin TV, smart screen, and other fields. As the construction of new infrastructure is in processing like a raging fire , there will be bringing more and more opportunity for the development of the planar transformer.
