IoT Application

JASN is China manufacturer & supplier who mainly produces Lan Transformer with many years of experience for IoT Application. PN G96T12DU can support Quad channel 1000M application.

Model:G96T12DU

Model:G96T12DU

High quality IoT Application is offered by China manufacturer JASN. Buy IoT Application which is of high quality directly with low price.

Feature

Compliant with IEEE802.3bt standard.
Comply with RoHS requirements.
Designed to support applications up tp 1100mA Per centre tap.
Operating temperature range: -40℃ to +85℃.
Storage temperature range: -40℃ to +125℃.

Electrical Specifications @ 25℃

OCL:	350uH Min. @100KHz/0.1V with 18mA DC Bias
Hi-POT :	1500Vrms
Turn Ratio:	1:1±3%
LK:	0.5uH Max @100KHz/0.2V
Cw/w	35pF Max @100KHz/0.2V
D.C.R:	1.4 ohm Max
Insertion Loss:	1-100MHz: -1.4dB Max
Cross Talk :	1-100MHz: -30dB Min
CMRR:	1-100MHz: -30dB Min
Return Loss:	1-40MHz	40-100MHZ
	-16dB Min	-10+20log(f/80)dB Min
