Isolation Transformer

JASN is one of the famous China Isolation Transformer manufacturers and suppliers. Our factory specializes in manufacturing of T1/E1 Transformer.

Model:H40C06SW

Model:H40C06SW

Send Inquiry

PDF DownLoad

High quality Isolation Transformer made in China. JASN is a Isolation Transformer manufacturer and supplier in China.


Feature


Comply with ROHS requirements.
Operating temperature range: -40℃ to +85℃.
Storage temperature range: -40℃ to +105℃.

Electrical Specifications @ 25℃



OCL:

Pri= 1.5mH Typ. @100KHz/0.05V

OCL:

Pri= 600uH Min @-40℃. @100KHz/0.05V

Choke OCL:

30uH Typ. @100KHz/0.05V

Hi-POT :

1500Vrms

Turn Ratio:

TX=1:2±3% RX=1:1±3%

LK:

Pri= 0.5uH Max @100KHz/0.05V

Cw/w

35PF Max @100KHz/0.05V

D.C.R:

Pri= 0.8 ohm Max

Crosstalk:

-60dB Typ @0.5-5MHz
